Price: 8700 USD
Under the condition of not affecting the load, TITAN 12m container skeletal semi trailer's body is lighter, and the tire wear and fuel consumption are smaller.
TITAN 12m container skeletal semi trailer can transport two 20-foot standard shipping container or carry one 40-foot standard shipping container. .TITAN brake air pipe adopts high pressure rubber air pipe, the service life is more than 10 years. Wires are cables. The service life is more than 5 years.
Meanwhile, TITAN is using the world famous brand parts on the skeletal semi trailer, such as Jost landing gear, Wabco Systerm.
12M Container Skeletal Semi Trailer for Sale Manufacturers
12M Container Skeletal Semi Trailer for Sale Manufacturers
12M Container Skeletal Semi Trailer for Sale Manufacturers
12M Container Skeletal Semi Trailer for Sale Manufacturers
Dimension(mm): 12300x2500x1520mm
Loading capacity(ton): ≤60T
Axles: 2 axle
Tire: 8 units, 12.00R22.5 or 315/80R22.5
Rim: 9.00-22.5 or 9.75-22.5
Suspension: Mechanical suspension
Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets)
King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)
Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)
Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel
Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank
Twist Locks: 4,8,12 sets (lifting or screw type)
Valve: WABCO valve (specially intended for oversea market)
ABS: Optional
Light: LED light (specially intended for oversea market)
Voltage: 24V
Socket(Receptacle): 7-pin Socket (for 7 wire harness)
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats
Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)
Shipping Terms: Transported by the bulk carrier in an RORO or 40ft container
Video of 12M Container Skeletal Semi Trailer
Through the video, you can know different types of skeleton trailers, as well as the process, testing, packaging and customer feedback, etc.
